TC430-M5-C6-WW60EL
Image may not correspond to reality
  • TC430-M5-C6-WW60EL
  • TC430-M5-C6-WW60EL

TC430-M5-C6-WW60EL

HSS-E-PM machine thread formers

Supreme

TC430-M5-C6-WW60EL
4042446291594
Walter AG
€60.76

€60.76 tax incl.

within 1 week
Quantity
in stock at the supplier

Description

  • For long-chipping materials
  • ISO M only with oil

HSS-E-PM machine thread formers TC430 • Supreme • ≤3,5xD • M/6HX • DIN 2174° • Suitable for blind hole • Suitable for through hole • WW60EL • M 5 • P=0,8mm

Product Details

Main application
ISO P
Additional application
ISO K
ISO M
ISO N
Thread size [D N]
M 5
Thread pitch [P]
0,8 mm
Functional length [l 1]
70 mm
Cutting edge length [L c]
8 mm
Clamping width
4,9 mm
Useable length [l 3]
25 mm
Driving square length [l 9]
8 mm
Number of grooves [N]
5
Connection diameter [d 1]
6 mm
Weight
0.014 kg
