P28519-BSW3/8
Image may not correspond to reality
  • P28519-BSW3/8
  • P28519-BSW3/8

P28519-BSW3/8

HSS-E machine taps
P28519-BSW3/8
4042446239480
Walter AG
€47.11

€47.11 tax incl.

within 1 week
Quantity
in stock at the supplier

Description

  • For long-chipping materials

HSS-E machine taps • Paradur Xpert P • ≤3xD • BSW/MEDIUM • DIN 2184-1 • right hand flute 45° • Suitable for blind hole • BSW 3/8-16 • P=16

Product Details

Thread size [DNN-P]
BSW 3/8-16
Thread size [D N]
9,525 mm
Threads per inch
16
Functional length [l 1]
100 mm
Cutting edge length [L c]
15 mm
Clamping width
8 mm
Useable length [l 3]
39 mm
Driving square length [l 9]
11 mm
Number of grooves [N]
3
Connection diameter [d 1]
10 mm
Weight
0.051 kg
