Image may not correspond to reality
Millimess 1004 Z
Dial comparator
€246.38 - €267.53
€246.38 - €267.53 tax incl.
within 1 week
Features
- Large, high contrast dial face
- Adjustable tolerance markers
- Lockable fine adjustment screw
- Shockproof movement
- Mounting shank and measuring spindle are both made of hardened stainless steel
- Measuring spindle is mounted in a high precision ball guide for minimal hysteresis
- Resistant to lateral forces (side play) acting on the measuring spindle
- Maximum sensitivity and accuracy are ensured by the jeweled movement in conjunction with the precision gears and pinions
- Box type protective housing
- Constant measuring force
- Measuring spindle can be retracted with either a screw in cable release or with a lifting knob
Filter By:
| Reference | Measuring force | Repeatability (inch) | Dial color | Error limit Ge (inch) | Error limit Gges (inch) | Error limit Gt (inch) | Readings (inch) | Standard | Calibration certificate | Weight | Availability | Price (tax excl.) | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 4333900 | 1 N | 0.0000" | White | 0.0001" | 0.00012" | 0.000050" | 0.0001" | Factory standard | 0.265 kg | in stock at the supplier | €246.38 |
|
4333900KAL | 1 N | 0.0000" | White | 0.0001" | 0.00012" | 0.000050" | 0.0001" | Factory standard | Mahr Factory | 0.265 kg | in stock at the supplier | €262.48 |
|
4333900DKS | 1 N | 0.0000" | White | 0.0001" | 0.00012" | 0.000050" | 0.0001" | Factory standard | DAkkS | 0.265 kg | in stock at the supplier | €267.53 |
|
Product Details
- Package contains
- adapter bush 940, 8 mm to 3/8"
case
test certificate - Figur on dial face
- .005"-0-.005"
- Scale diameter (mm)
- 50 mm
- Hysteresis error of the measured value (inch)
- 0.00003 "
- Shockproof movement
- true
- Measuring range, test indicator, comparator, probe (inch)
- ± .0050"
- Measuring range beginning (inch)
- -0.005 "
- Measuring range end (inch)
- 0.005 "
Mahr Millimess 1004 Z
Dial comparator
