Image may not correspond to reality
Millimess 1004 T
Dial comparator
€267.72 - €288.87
€267.72 - €288.87 tax incl.
within 1 week
Features
- Large, high contrast dial face
- Adjustable tolerance markers
- Lockable fine adjustment screw
- Shockproof movement
- Mounting shank and measuring spindle are both made of hardened stainless steel
- Measuring spindle is mounted in a high precision ball guide for minimal hysteresis
- Resistant to lateral forces (side play) acting on the measuring spindle
- Maximum sensitivity and accuracy are ensured by the jeweled movement in conjunction with the precision gears and pinions
- Box type protective housing
- Constant measuring force
- Measuring spindle can be retracted with either a screw in cable release or with a lifting knob
Filter By:
| Reference | Measuring force | Repeatability (µm) | Error limit Ge (µm) | Error limit Gges (µm) | Error limit Gt (µm) | Readings (µm) | Measuring range beginning (µm) | Measuring range end (µm) | Dial color | Standard | Calibration certificate | Weight | Availability | Price (tax excl.) | 4333005 | 1 N | 1 µm | 3.5 µm | 4 µm | 3 µm | 5 µm | -130 µm | 130 µm | White | Factory standard | 0.265 kg | in stock at the supplier | €267.72 |
|
4333005KAL | 1 N | 1 µm | 3.5 µm | 4 µm | 3 µm | 5 µm | -130 µm | 130 µm | White | Factory standard | Mahr Factory | 0.265 kg | in stock at the supplier | €283.82 |
|
4333005DKS | 1 N | 1 µm | 3.5 µm | 4 µm | 3 µm | 5 µm | -130 µm | 130 µm | White | Factory standard | DAkkS | 0.265 kg | in stock at the supplier | €288.87 |
|
|---|
Product Details
- IP protection category
- IP 54
- Package contains
- case
test certificate - Figur on dial face
- 130-0-130
- Hysteresis error of the measured value (µm)
- 1 µm
- Overtravel (mm)
- 2.5 mm
- Scale diameter (mm)
- 50 mm
- Measuring range, test indicator, comparator, probe
- ± 0.13
- Measuring range beginning (mm)
- -0.13 mm
- Measuring range end (mm)
- 0.13 mm
- Shockproof movement
- true
Mahr Millimess 1004 T
Dial comparator
